Flame-retardant Tape

Flame Retardant Double Sided Tape

UL94 V-0 · Self-extinguishing

LubandArt manufactures Flame Retardant Double Sided Tape built on a Flame-retardant carrier with pressure-sensitive adhesive. Thickness, width, roll length, adhesive system and release liner can be customized according to the substrate, application environment and production requirements.

Base
Flame-retardant
Thickness Range
0.05 – 0.30 mm
Temperature Range
-20 ~ 120 ℃
Get a quoteConfigure options
  • ISO 9001 manufacturer
  • RoHS / REACH reports available
  • Reply within one business day
Flame Retardant Double Sided Tape
Jumbo · Converted · Finished
01

Jumbo Roll

Master rolls supplied by width and length for converters and die-cutters — ready for your own slitting and converting.

02

Converted Roll

Slit and rewound to your required width, roll length, liner and core — direct-application rolls for wholesalers and distributors.

03

Finished / Die-Cut

Die-cut shapes and parts produced to drawing, ready to apply on your assembly line with no further conversion.

Key Benefits

Why Choose Flame Retardant Double Sided Tape

01

UL94 rating evaluated per project

02

Smoke and burn performance confirmed by model

03

Stable bond to metal and plastic

04

Suitable for battery packs and electrical assemblies

Construction

Flame Retardant Double Sided Tape Structure

Double-sided flame-retardant tape consists of a flame-retardant carrier coated on both sides with pressure-sensitive adhesive and protected by release liners.

Layer order shown for reference. Adhesive chemistry and carrier density are confirmed against the selected specification.

Specifications

Technical Specifications

Base MaterialPET / flame-retardant tissue
Thickness Range0.05 – 0.30 mm
Temperature Range-20 ~ 120 ℃
Adhesive SystemFlame-retardant acrylic
Flame Retardant RatingUL94 V-0 (per test report; confirm by model)

Ranges above are typical. Final values are confirmed by the selected construction and test report. Non-standard thickness, width, roll length and die-cut formats are available.

Need a value outside these ranges?Send this configuration →
Product Reference

Structure & Suitable Substrates

Visual references are provided for selection. Final construction and substrate suitability are confirmed against the project specification and sample test.

Flame Retardant Double Sided Tape structure diagram: release liner, adhesive layers and foam carrier
Commercial Information

Samples, MOQ & Lead Time

Final commercial terms depend on tape construction, width, roll length, packaging and order quantity. Send the target specification for a confirmed quote.

SamplesStandard samples can be requested; availability and preparation time are confirmed by specification.
MOQProject-based. Standard and custom constructions may have different minimum quantities.
Lead timeConfirmed after sample approval, specification lock and production planning.
DownloadsCatalog, certificates and selected test reports are available below.
Customize

Configure Flame Retardant Double Sided Tape for Your Application

Select adhesive system, carrier thickness, release liner and converting format for your substrate, environment and assembly process.

Adhesive System
Thickness & Width
Release Liner
Converting Format

Select the options that matter to you — they are attached to your inquiry automatically.

Flame Retardant Double Sided Tape custom converting line
CUSTOM CONVERTINGSlitting · Laminating · Die-Cutting
SAMPLEavailability confirmed by specification
100%spec confirmation before bulk
CUSTOMslitting width confirmed by project
OEM/ODMbranding & packaging supported
Applications

Where Flame Retardant Double Sided Tape Works

From automotive trim to electronics assembly, the same construction adapts across industries.

  • Battery pack fixing
  • Electronic & electrical assembly
  • PCB temporary fixing
  • Power battery module
Industries

Flame Retardant Double Sided Tape Across Industries

Automotive AssemblyAutomotive AssemblyConstruction & FacadeConstruction & FacadeElectronicsElectronicsHome ApplianceHome ApplianceSignage & DisplaySignage & DisplayMechanical & IndustrialMechanical & Industrial
OEM & Supply

Custom Supply & OEM

One coordinated production line handles coating, converting and export packaging under controlled quality.

From pilot sample to bulk shipment

One coordinated production line handles coating, converting and export packaging under controlled quality.

Typical MOQ

Depends on model, width, length, adhesive system and customization level. Trial orders on standard specs are welcome.

Sample Lead Time

Confirmed after reviewing the requested specification, stock position and sample format.

Bulk Production

Usually 7–10 working days, depending on specification, converting requirements and quantity.

OEM Customization

Width, thickness, roll length, adhesive system, density, color, liner, core, printing and packaging can all be customized.

Process

From Requirement to Mass Production

A streamlined workflow designed to deliver reliable, high-performance adhesive solutions.

  1. 01

    Requirement Analysis

    Evaluate application environment, stress factors and bonding parameters.

  2. 02

    Material Selection

    Match carrier and adhesive chemistry to your technical requirements.

  3. 03

    Sample Confirmation

    Produce precision prototypes for client-side testing and validation.

  4. 04

    Mass Production

    Scaled manufacturing with controlled coating, laminating and converting.

  5. 05

    Quality Inspection

    Test peel adhesion, shear strength and dimensional accuracy.

  6. 06

    On-Time Delivery

    Pack per agreed requirements and prepare for shipping.

FAQ

Frequently Asked Questions about Flame Retardant Double Sided Tape

Is flame-retardant tape UL94 V-0 certified?
Some flame-retardant constructions can be tested to UL94 or other project standards. The rating depends on thickness and the complete tape construction, so request the certificate for the selected grade before specifying it.
What is the temperature range of flame-retardant tape?
Standard grade: -20°C to 120°C continuous, with short-term peaks up to 150°C during battery pack assembly or paint bake. For higher service temperatures we offer a high-temperature flame-retardant grade rated to 150°C continuous.
Will flame-retardant tape drip when exposed to flame?
Dripping and self-extinguishing behavior must be confirmed from the test report for the selected construction. Do not infer fire performance from the carrier alone.
Can flame-retardant tape be used in battery packs?
Yes — this is one of its main applications. The tape is used for cell-to-cell bonding, module-to-pack fixing, and busbar insulation in EV battery packs. We supply low-impedance / dielectric versions on request for electrical isolation layers.
How does flame-retardant tape differ from regular PET tape?
Standard PET and flame-retardant constructions differ in carrier and adhesive formulation. Compare the full construction, thickness and test report; a flame-retardant carrier alone does not establish a UL94 result.
Is flame-retardant tape available in custom thicknesses and widths?
Yes — 0.05-0.30 mm thickness and slit widths from 5 mm to 1040 mm. Custom die-cut shapes for battery pack assembly, PCB masking and electrical insulation are supplied to drawing with lot-traceable documentation.
