PET Tape

Double Sided PET Tape

Ultra-thin · Dimensionally stable

LubandArt manufactures Double Sided PET Tape built on a PET carrier with pressure-sensitive adhesive. Thickness, width, roll length, adhesive system and release liner can be customized according to the substrate, application environment and production requirements.

Base
PET
Thickness Range
0.02 – 0.20 mm
Temperature Range
-20 ~ 120 ℃
Get a quoteConfigure options
  • ISO 9001 manufacturer
  • RoHS / REACH reports available
  • Reply within one business day
Double Sided PET Tape
Jumbo · Converted · Finished
01

Jumbo Roll

Master rolls supplied by width and length for converters and die-cutters — ready for your own slitting and converting.

02

Converted Roll

Slit and rewound to your required width, roll length, liner and core — direct-application rolls for wholesalers and distributors.

03

Finished / Die-Cut

Die-cut shapes and parts produced to drawing, ready to apply on your assembly line with no further conversion.

Key Benefits

Why Choose Double Sided PET Tape

01

Ultra-thin carrier that saves space

02

Dimensionally stable, resists stretching

03

Lays flat without curling

04

Suited to precision die-cutting

Construction

Double Sided PET Tape Structure

Double-sided pet tape consists of a pet carrier coated on both sides with pressure-sensitive adhesive and protected by release liners.

Layer order shown for reference. Adhesive chemistry and carrier density are confirmed against the selected specification.

Specifications

Technical Specifications

Base MaterialPET film
Thickness Range0.02 – 0.20 mm
Temperature Range-20 ~ 120 ℃
Adhesive SystemAcrylic pressure-sensitive adhesive
Release LinerDouble-sided release film

Ranges above are typical. Final values are confirmed by the selected construction and test report. Non-standard thickness, width, roll length and die-cut formats are available.

Need a value outside these ranges?Send this configuration →
Product Reference

Structure & Suitable Substrates

Visual references are provided for selection. Final construction and substrate suitability are confirmed against the project specification and sample test.

Double Sided PET Tape structure diagram: release liner, adhesive layers and foam carrier
Commercial Information

Samples, MOQ & Lead Time

Final commercial terms depend on tape construction, width, roll length, packaging and order quantity. Send the target specification for a confirmed quote.

SamplesStandard samples can be requested; availability and preparation time are confirmed by specification.
MOQProject-based. Standard and custom constructions may have different minimum quantities.
Lead timeConfirmed after sample approval, specification lock and production planning.
DownloadsCatalog, certificates and selected test reports are available below.
Customize

Configure Double Sided PET Tape for Your Application

Select adhesive system, carrier thickness, release liner and converting format for your substrate, environment and assembly process.

Adhesive System
Thickness & Width
Release Liner
Converting Format

Select the options that matter to you — they are attached to your inquiry automatically.

Double Sided PET Tape custom converting line
CUSTOM CONVERTINGSlitting · Laminating · Die-Cutting
SAMPLEavailability confirmed by specification
100%spec confirmation before bulk
CUSTOMslitting width confirmed by project
OEM/ODMbranding & packaging supported
Applications

Where Double Sided PET Tape Works

From automotive trim to electronics assembly, the same construction adapts across industries.

  • Display thin bonding
  • Plastic-part precision fixing
  • Nameplate / label
  • Film lamination
Industries

Double Sided PET Tape Across Industries

Automotive AssemblyAutomotive AssemblyConstruction & FacadeConstruction & FacadeElectronicsElectronicsHome ApplianceHome ApplianceSignage & DisplaySignage & DisplayMechanical & IndustrialMechanical & Industrial
OEM & Supply

Custom Supply & OEM

One coordinated production line handles coating, converting and export packaging under controlled quality.

From pilot sample to bulk shipment

One coordinated production line handles coating, converting and export packaging under controlled quality.

Typical MOQ

Depends on model, width, length, adhesive system and customization level. Trial orders on standard specs are welcome.

Sample Lead Time

Confirmed after reviewing the requested specification, stock position and sample format.

Bulk Production

Usually 7–10 working days, depending on specification, converting requirements and quantity.

OEM Customization

Width, thickness, roll length, adhesive system, density, color, liner, core, printing and packaging can all be customized.

Process

From Requirement to Mass Production

A streamlined workflow designed to deliver reliable, high-performance adhesive solutions.

  1. 01

    Requirement Analysis

    Evaluate application environment, stress factors and bonding parameters.

  2. 02

    Material Selection

    Match carrier and adhesive chemistry to your technical requirements.

  3. 03

    Sample Confirmation

    Produce precision prototypes for client-side testing and validation.

  4. 04

    Mass Production

    Scaled manufacturing with controlled coating, laminating and converting.

  5. 05

    Quality Inspection

    Test peel adhesion, shear strength and dimensional accuracy.

  6. 06

    On-Time Delivery

    Pack per agreed requirements and prepare for shipping.

FAQ

Frequently Asked Questions about Double Sided PET Tape

Why choose PET film tape over tissue or OPP tape?
PET carrier is dimensionally stable, has higher temperature resistance (up to ~150-200°C depending on grade) and is unusually thin for its tensile strength. That makes it ideal for electronics, membrane switches, graphic overlays and any application where the tape must not stretch during processing.
What is the thinnest PET tape you supply?
From 0.05 mm total thickness upward. Very thin PET tape is widely used in mobile electronics, RFID inlay bonding and FPC grounding — we can also supply 0.025 mm ultra-thin variants on request.
Does PET tape offer electrical insulation?
Yes — PET is a good dielectric and our PET double-sided tape is used as an insulation / bonding layer in transformers, batteries and consumer electronics. Dielectric data is available on request.
Can PET tape survive reflow-solder or wave-solder processes?
Selected grades with high-temperature acrylic adhesive are designed for SMT reflow and selective wave-solder masking. Send us your thermal profile and we will recommend a tested grade rather than asking you to find out in production.
Can PET tape be laser-cut?
Yes — PET is one of the cleanest laser-cutting carriers. Common for RFID tag production, smartphone gaskets and small die-cut shapes. We can supply laser-cut parts to drawing with tight tolerance.
Is PET tape die-cuttable for precision parts?
Yes — PET die-cuts extremely cleanly and is the standard choice for precision parts in electronics and medical devices. Standard tooling or digital cutting both supported.
